MaxLYTE ELECTROLYTE ANALYZER
INTENDED USE: Designed for accurate and reliable analysis with user-friendly operation, ensuring precise results with minimal maintenance.
Product Fearures:
- Sample Size: 100 μL.
- Sample Type: Whole Blood, Serum, Plasma, Urine etc.
- Sample Application – Syringe, Sample Cup, Collection Tubes, Capillary.
- Analysis Time: 55 Seconds.
- Weight: 6 Kgs (13 Lbs) Approx.
- Printout: Built-in, Thermal Roll Printer; 32 Characters Wide
- Electronic: Microprocessor Controlled.
- Relative Humidity: < 85%, Non-condensing.
- Normal Value: Flagging Of Abnormal Results; User Programmable Ranges.
- Calibration: Fully Automatic, 1-point With Every Sample; 2-point Every 4 Hours.
- Power Requirements: 110-240 V, 50/60 Hz (self-adjusting) 1.4 Amp Max.
Categories: Instruments
- Electrolyte Analyzer
- 1000 samples per pack
- One set of reagent pack is common for all 10 combinations
- Intelligent reagent pack with electronic chip
- Principle: Direct measurement with ion selective electrode (ISE)
- Parameters: Electrolytes Na⁺, K⁺, iCa²⁺, Li⁺, pH, Cl⁻, Calculated parameters nCa, TCa
- Sample Type: Whole blood, serum, plasma, CSF and diluted urine
- Sample Volume: 120 µL for whole blood, serum, plasma, CSF and 500 µL for diluted urine
- Calibration: Automatic or on-demand
- Analysis Time: 55 seconds
- Throughput: 55 samples/hour
- Data Storage: 10000 samples, 250 urine & 100 QC
- Ambient Condition: Storage & operating temperature 5°C to 40°C (41°F to 104°F), relative humidity 10–90%
- Display: 128 × 64 graphics display with alphanumeric keypad
- Connectivity: USB Type B port (LIS)
- Print Out: Built-in 2 inch 24 column thermal printer
- Power Supply: 100–240V AC, 50/60Hz, 1.4A
- Size & Weight: 9″ W × 15.7″ H × 12.6″ D, weight 5.4 kg (without reagent pack)
- Battery: Optional (2 hours in standby mode)
